NEO-LH100 SITRANS Hydrostatic Level Transmitter
The pressure transmitter LH100 is a well probe and converts the level-proportional hydrostatic pressure into a standard signal of 4 - 20 mA. It measures levels in basins, containers, canals and dams. It has a stainless steel housing and a piezoresistive sensor with a ceramic membrane and is available for a wide range of measuring ranges and, if required, with explosion-protection.
Technical Details
| Accuracy | 0,3 % |
| Long-term stability | 0,25 % / 12 months |
| Measuring range | 0-3 mH2O to 0 – 20 mH2O |
| Housing | 316L stainless steel housing (Ø 23.4 mm), IP68 rated |
| Cable | PE sheathing; Ø 6 mm with vent pipe |
| Cable length | standard 10, 20, or 30 m, special lengths up to 50m are possible |
Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.
For more information about this product, download the catalog.
NEO-LH100 SITRANS Hydrostatic Level Transmitter
The pressure transmitter LH100 is a well probe and converts the level-proportional hydrostatic pressure into a standard signal of 4 - 20 mA. It measures levels in basins, containers, canals and dams. It has a stainless steel housing and a piezoresistive sensor with a ceramic membrane and is available for a wide range of measuring ranges and, if required, with explosion-protection.
Technical Details
| Accuracy | 0,3 % |
| Long-term stability | 0,25 % / 12 months |
| Measuring range | 0-3 mH2O to 0 – 20 mH2O |
| Housing | 316L stainless steel housing (Ø 23.4 mm), IP68 rated |
| Cable | PE sheathing; Ø 6 mm with vent pipe |
| Cable length | standard 10, 20, or 30 m, special lengths up to 50m are possible |
For more information about this product, download the catalog.
Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.
