NEO-LPS200 SITRANS Rotary Paddle Level Switch
The LPS200 is a rotating paddle point level detector, designed for reliable high or low level detection in silos and hoppers containing bulk solids. Unlike continuous measurement systems, the LPS200 acts as a mechanical switch: when a product (grain, cement, plastic pellets) stops the rotation of its paddle, it immediately triggers an alarm or stops the filling process. Robust and ready to use, it withstands extreme temperatures up to 600 °C and offers SIL2 certified functional safety, making it ideal for inventory management and overflow protection in the food, agricultural, and heavy industries.
Technical Details
| Range | 100 mm to 10 m (4 inch to 30 ft) |
| Process Temperature | -25 to 600 °C (-13 to 1112 °F), higher temperatures upon request |
| Process Pressure | Up to 10 bar g (145 psi g) |
| Bulk densities | Starting at 15 g/l (0.9 lb/ft³) with optional vane |
| Versions available | Compact, rigid extended, cable extended, angle extended |
| Options | Functional Safety (SIL 2). Device suitable for use in accordance with IEC 61508 and IEC 61511 Fail-safe configuration High-temperature model Extension kit (cable or rigid) Universal power supply |
| Key Applications | Bulk solids such as grain, feed, cement, plastic granulate, wood chips |
Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.
For more information about this product, download the catalog.
