Economical Conductivity Sensor
Liquid Analysis›Conductivity

Economical Conductivity Sensor

The Economical Conductivity Sensor from Neodyn is suitable for measurements in agricultural applications, water treatment, the food industry, and ultra-pure water applications. With its AISI316 stainless steel electrode material and robust PP or PVC body, it delivers reliable performance even in precision applications. Measuring range from 0.1 to 2000 µS up to 20 S, max temperature 80°C, max pressure 6 bar. Integrated PT100-PT1000 temperature sensor.

Technical Details

Measurement Range0.1...2000 µS - 0.01...20 S
Process Connection3/4" Male BSP
Operating TemperatureMax. 80°C (176°F)
Operating PressureMax. 6 Bar (85 Psi)
BodyPVC, PP
Temperature SensorPT100-PT1000
Electrode MaterialStainless Steel AISI316
Qty
Global Shipping

For more information about this product, download the catalog.

Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.

Contact Expert
1

Explore More

We suggest other products that may also be helpful to you

Electronic Pressure Switch MSPS
Pressure switches
Pressure measurement

Electronic Pressure Switch MSPS

The MSPS is a user-friendly and cost-effective electronic pressure switch designed by Mesens for pressure monitoring and control in industrial applications. It allows easy adjustment of the desired pressure using the integrated keypad and real-time monitoring of the pressure value and scale percentage via its OLED graphic display. Consisting essentially of a pressure transmitter and a loop-powered indicator, it offers a compact and reliable all-in-one solution. With adjustment ranges from 0-100 mbar to 0-600 bar and versatile connections (G1/4', G1/2' to 1" flush diaphragm, DN40-DN50, Tri-Clamp), it adapts to all applications. Featuring a 4-20 mA output and two configurable PNP/NPN outputs, a SS316L diaphragm, and an aluminum housing with IP65 protection, the MSPS is perfect for the chemical, pharmaceutical, food and beverage, and industrial hydraulics industries.

View Details
Exproof Pressure Switch PS-X
Pressure switches
Pressure measurement

Exproof Pressure Switch PS-X
